Specifications

• Productivity (per hour): Theoretical Max: 45,760 ft2; Estimated coverage (conventional) 23,760 ft2
• Brush Size: (2 disc) 13"
• Hygenic[TM] Solution Tank: 29 Gal.
• Hygenic[TM] Recovery Tank: 29 Gal.
• Brush Speed: 225 rpm
• Brush Down Pressure: (3 settings) 80, 120, & 160 lb.
• Vacuum Fan: 0.6 hp
• Transport Propel Speed Forward: Variable to 4 mph
• Working Propel Speed Forward: Variable to 3.6 mph
• Propel Speed Reverse: Variable to 2.5 mph
• Speed Control: Electronic
• Incline Propelling: Transport (empty for trailering) 11 deg; Transport at gross weight 6 deg; Working (scrubbing) 4 deg
• Maximum Continuous Run Time: 3.0 hours
• Optional Heavy-Duty Capacity Batteries: 24 volt 335AH; maximum continuous run time 4.5 hours
• Safety System Standard Features: Seat switch, power shut-down switch, automatic breaking & parking brake
• Sound Level @ Operators Ear: 67 dBa
• Dimensions: 60" L x 31.5" W scrub head; 29" W frame (roller to roller); 33.25" W rear squeegee (roller to roller) x 50" H
• Minimum Aisle Turn: 68.5"
• Weight: 585 lbs. (w/o batteries); 850 lbs. (w/standard battery package); 975 lbs (w/heavy duty battery package)
• Maximum Tire Footprint Pressure: 175 psi
• Warranty: 3 MONTHS
